CONTEMPORARY
20–60mm F2.8–4 DG
NEW
contemporary
20–60mm F2.8–4 DG
Available mounts
- Combining a dynamic 20mm perspective with exceptional agility
- Uncompromising optical performance
- Reliability for effortless shooting
The freedom of a 20mm ultra-wide-angle lens. Surprisingly lightweight. Reimagining the standard zoom.
SPECIFICATIONS
FEATURES
LENS CONSTRUCTION / MTF
SAMPLE IMAGES
Camera Type
Mirrorless
Corresponding Mount
L-Mount
Sony E-Mount
Sony E-Mount
Sensor size
Full Frame [DG]
Lens Construction
15 elements in 11 groups (3 SLD, 1 FLD, and 3 aspherical lens elements)
Angle of View
L-Mount: 94.5°-39.6°
Sony E-Mount: 94.5°-39.6°
Sony E-Mount: 94.5°-39.6°
Number of Diaphragm Blades
9（Rounded diaphragm）
Minimum Aperture
F22-32
Maximum Magnification Ratio
1:2.3 at f=35mm
Filter Size
φ67mm
Dimensions (Diameter × Length)
L-Mount: φ72.2mm x 86.0mm / φ2.8in. x 3.4in.
Sony E-mount: φ72.2mm x 88.0mm / φ2.8in. x 3.5in.
*The length of a lens is measured from the front of the lens to its mount
Sony E-mount: φ72.2mm x 88.0mm / φ2.8in. x 3.5in.
*The length of a lens is measured from the front of the lens to its mount
Weight
L-Mount: 385g / 13.6oz.
Sony E-mount: 375g / 13.2oz.
Sony E-mount: 375g / 13.2oz.
Edition Number
C026
The three-digit code on the surface of the lens is to indicate the year the lens was first released.
(Since it is different from the year of manufacture, the release year and edition number may not match depending on the mount.)
The three-digit code on the surface of the lens is to indicate the year the lens was first released.
(Since it is different from the year of manufacture, the release year and edition number may not match depending on the mount.)
Supplied Accessories
Pouch
Lens Hood LH706-04
Front Cap LCF-67 IV
Rear Cap LCR III
Lens Hood LH706-04
Front Cap LCF-67 IV
Rear Cap LCR III
Mount / Product Barcode
L-Mount：0085126666699
Sony E-mount：0085126666651
Sony E-mount：0085126666651
Camera Compatibility
LINK
* The appearance and specifications of the product are subject to change. * This product is developed, manufactured and sold based on the specifications of E-mount which was disclosed by Sony Corporation under the license agreement with Sony Corporation. * Canon RF Mount is developed, manufactured and sold under license from Canon Inc.
.
| Camera | Sigma fp |
|---|---|
| Shutter Speed | 1/60s |
| Lens F Number | F4 |
| ISO | 100 |
| Focal Length | 60mm |
| Photographer | Kayoko Nemoto |
| Camera | Sigma fp |
|---|---|
| Shutter Speed | 1/1600s |
| Lens F Number | F3.7 |
| ISO | 100 |
| Focal Length | 35mm |
| Photographer | Kayoko Nemoto |
| Camera | Sigma fp |
|---|---|
| Shutter Speed | 1/160s |
| Lens F Number | F3.7 |
| ISO | 100 |
| Focal Length | 35mm |
| Photographer | Kayoko Nemoto |
| Camera | Sigma fp |
|---|---|
| Shutter Speed | 1/320s |
| Lens F Number | F2.8 |
| ISO | 100 |
| Focal Length | 20mm |
| Photographer | Kayoko Nemoto |
-
Lens construction
SLD glass Aspherical lensMTF CHART
Diffraction MTF
Diffraction MTF
Geometrical MTF
Geometrical MTF
Spatial frequencyS: Sagittal LineM: Meridional Line10lp/mm30lp/mmMTF CHART GUIDE
The MTF (Modulation Transfer Function) is one of the measurements for evaluating a lens’ performance, and it shows how faithfully the contrast of the subject can be reproduced on the image plane. The horizontal axis shows the image height (distance from the center of the image in mm) and the vertical axis shows the contrast value (maximum value is 1).
The closer the 10 line pairs/mm curve is to 1, the higher the contrast and clarity of the lens is, and similarly, the closer the 30 line pairs/mm curve is to 1, the better the resolution and sharpness of the lens is.
*The MTF chart depicts the result at the wide-open aperture.
*For mirrorless lenses that support distortion correction, the horizontal axis shows the image height equivalent to when an L-Mount lens is attached to a Sigma L-Mount camera with distortion correction applied. (The effect of distortion correction may differ depending on the mount and camera used.)
*The spatial frequency indicates the variation on the image plane before distortion correction is performed.
20-60mm: Freedom to compose
From an expansive 20mm ultra-wide to a natural 60mm perspective, this lens delivers a wide range of expression in a versatile zoom. Capture everything from sweeping landscapes to everyday snapshots and portraits—without changing lenses. With a maximum aperture of F2.8 at 20mm, you can shoot confidently in low light environments such as indoors and nightscapes, while keeping ISO low.
Bringing 20mm into your everyday
Weighing just 385g*1, this 3x zoom achieves an incredibly compact design—remarkable for an ultra-wide lens starting at F2.8. Its slim form fits easily into any bag, making it ideal for everything from daily snapshots and travel to hiking and video creation. Experience full-frame rendering performance with unprecedented portability. *1. The figure is for L-Mount.
Consistent high optical performance across the entire zoom range
While prioritizing improved potability, no compromises have been made in image quality. The optical design—featuring 15 elements in 13 groups, including three aspherical lenses and three SLD glass elements—delivers consistent sharpness throughout the entire zoom range. From everyday scenes to breathtaking travel moments, it renders every detail with striking clarity.
Macro capabilities for versatile expression
Impressive close-up capability expands shooting versatility. With a minimum focusing distance of 15.8 cm at 28mm and a maximum magnification ratio of 1:2.3 at 35mm, this lens delivers richly detailed close-up images approaching half-macro performance. Even at the 60mm telephoto end, it maintains a high magnification of 1:2.9—ensuring a seamless shooting experience across the zoom range, allowing full focus on composition without concern for subject distance.
Designed to minimize flare and ghosting
Flare and ghosting, which reduce image quality, are addressed under all conditions of incident light, based on the most advanced simulation technology. High backlight resistance enables clear and sharp images under any lighting conditions.
Fast and quiet autofocusing with HLA system
A linear motor HLA (High-response Linear Actuator) is employed for the AF actuator, delivering high-speed autofocus with high-precision drive to capture decisive moments. It also offers outstanding tracking performance for fast-moving subjects, even at high frame rates. Engineered for modern hybrid shooting, it ensures seamless performance across stills and video.
Minimal focus breathing
The lens is designed to minimize changes in the angle of view caused by focusing, enabling smooth, natural-looking focus pulls when recording video.
Dust- and splash-resistant structure*1 / water- and oil-repellent coating
In addition to a dust- and splash-resistant structure , the frontmost surface of the lens has a water- and oil-repellent coating applied, allowing photographers to shoot without concern even in harsh outdoor environments. *1. The product is designed to be dust- and splash-resistant but is not waterproof. When using the lens near water, etc., take care not to allow large amounts of water to splash on it. If water gets inside the lens, it may cause a major malfunction.
